VIALED NET

  • Emergency unit for Vialed series
  • Allows a star or cascade connection
IP20

List of results, divided by function

RECESSED INSTALLATION INSIDE OF PT JUNCTION BOXES

HOW TO COMPOSE YOUR SYSTEM

  • Select a code for the power kit (Vialed Net)
  • Select 1 to 4 codes for spotlights Vialed to match the power kit (Vialed Evo, Vialed High, Vialed Wall and Vialed Tube with Vialed Net function)

The spot with the Vialed Net function cannot be purchased individually.

CONNECTIONS

The kit to install in the junction boxes of the installation allows totally flexible connection of 4 Vialed devices.




"STAR" connection
"CASCADE" connection
"MIXED" connection

Box sold separately.

CABLE CROSS-SECTIONS AND LENGTHS

    0,75 mm2 1,5 mm2 2,5 mm2
"START" connection MAX distance of each light from central unit 40 m 80 m 140 m
"CASCADE" connection MAX distance of light farther from central unit* 40 m 80 m 140 m


* MAX distance between each light with “cascade” installation: 20 m

TECHNICAL FEATURES

  • Maximum battery charge time of 12h
  • Compliant with European standards EN 60598-2-22, EN 61347-1

INSTALLATION

Vialed Net can be mounted recessed inside junction boxes PT6 type or larger (not included)
